Reverse Rotation EWG Manifold
A cast top-mount turbo manifold for the Mazda MX-5 NA and NB, made in-house from NiResist D5S Type 2 for reverse-rotation turbos, with a V-band turbine flange and an external wastegate.
Made by Kraken
Built in our own European workshop, start to finish.
Shipped by air
Dispatched worldwide, fully tracked.
- If it fails, we replace it→
If a part we made fails, we make you a new one.
Questions about fitment?
Send us a message →Reverse Rotation EWG Manifold
€650.00
Complete kit
Build the complete kit
This part is also in the Turbo Kit Builder. Configure a full bolt-on system and order it in one go.
Open the kit builder →The Reverse Rotation Top Mount Manifold.
The reverse-rotation manifold is cast in-house from NiResist D5S Type 2 as a top-mount design for the NA and NB. It is built for reverse-rotation turbochargers, spinning the compressor counter-clockwise and turning the outlet toward the front of the bay. In the compact MX-5 engine bay, that shortens the charge-pipe run and removes bends, lowering pressure loss. The wastegate mounts externally, on a V-band 38mm or 44mm flange.
Outlet To The Front
The manifold is built for reverse-rotation turbochargers, spinning the compressor counter-clockwise and turning the outlet toward the front of the engine bay rather than the firewall. In the compact MX-5 bay, that shortens the charge-pipe run and removes bends.
Boost Control Off The Housing
The wastegate mounts externally, on a V-band flange sized for a 38mm or 44mm gate, keeping boost control off the turbine housing. That reduces the exhaust reversion of an internal-wastegate setup, holds turbine efficiency at higher boost, and gives a separate dump for exhaust-pulse management.
Cast In NiResist D5S
The manifold is cast in-house from NiResist D5S Type 2, a high-nickel iron used for turbine housings, providing resistance to exhaust heat and cracking. The top-mount casting clears the bonnet and the air-conditioning compressor, and mounts the turbo on a V-band flange.
Specifications
Manifold Questions
What is reverse rotation?+
The turbo's compressor spins counter-clockwise, turning the outlet toward the front of the bay rather than the firewall. In the compact MX-5 engine bay, that shortens the charge-pipe run and removes bends.
Which turbos fit this manifold?+
Reverse-rotation external-wastegate turbos with a V-band inlet, in the G25 frame, such as the PSR G25-550 and G25-660 or the Garrett G25-585.
Internal or external wastegate?+
External, on a V-band flange sized for a 38mm or 44mm gate, keeping boost control off the turbine housing.
Does it clear the bonnet and air conditioning?+
Yes. The top-mount casting clears the bonnet and the air-conditioning compressor.
Which engines does it fit?+
The 1.6 B6 and 1.8 BP engines in the Mazda MX-5 NA and NB (1989 to 2005). Choose 1.6 or 1.8 at order.
What is the manifold made from?+
NiResist D5S Type 2, a high-nickel cast iron used for turbine housings, providing resistance to exhaust heat and cracking.
